Publicado: 29 de junho de 2026 · Categoria: Catálogos

Deste documento

SHIELDED CABLES ELEZ BARRYFLEX SHIELD RC4V-K 0,6/1 0,6/1kV kV LEZ AFIRENAS SHIELD Z1C4Z1-K (AS) 0,6/1kV Z AFIREFENIX AFIREFENIX SHIELD SHIELD SOZ1-K SOZ1-K (AS+) (AS+) 300/500 300/500 VV PH120 PH120 C A B L E S O F R AT E D V O LTA G E 3 0 0 / 5 0 0 V & 4 5 0 / 7 5 0 V BARRYFLEX SHIELD H05VVC4V5-K DoP : MEH05VVC4V5K. 70ºC 160ºC mm2 Max. conductor temperature Cu class 5 flexible 300/500 V Multiconductor Rated voltage Electromagnetic Oil resistant cable protection High flexibility IEC 60332-1-2 Shielded cable • Standard (construction/tests): EN 50525-2-51. • Technical designation: H05VVC4V5-K. • Construction: Conductor: Copper, class 5 / Insulation: PVC type TI2 / Inner Sheath: PVC type TM2 / Shield: Copper braid / Oversheath: PVC type TM5. • Rated voltage (Uo/U): 300/500 V AC. • Max. conductor temperature. Normal operation / short-circuit (t≤5s): 70 ºC / 160 ºC. • Range: Multiconductor cable. Cross-sectional area: From 0.5 to 2.5 mm2. • Reaction to fire classification (CPR - EN 50575 & EN 13501-6): Eca. • Other fire performance features (when CPR Regulation is not applicable): Flame retardant (IEC 60332-1-2). • Applications: Shielded cable suitable for fixed installations that require electromagnetic protection. Especially designed for the interconnection of parts of machines intended for manufacturing, including machine tools, where some degree of protection against electromagnetic interference is necessary and in the case of applications requiring resistance to general...
